Quality High Vacuum Continuous Casting Machine Manufacturer for Making High Quality Gold Silver Copper Alloy Hasung
High Vacuum Continuous Casting Machine compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Hasung summarizes the defects of past products, and continuously improves them. The specifications of High Vacuum Continuous Casting Machine can be customized according to your needs.
Product Introduction
Vacuum Continuous Casting Machines / High Vacuum Continuous Casting Machines
HVCC Vacuum Continous Casting machines have been design with the most up-to-date technologies to give you semi-finished products with the best quality such as high quality high density gold, silver, copper, alloys, etc.
With only one machine, you will be able to obtain the semi-finished product you desire, such as:
Wires, from 4 to 16 mm Ø,
Sheets,
Tubes,
HVCC machines are equipped with Gas Wash Purge procedure which removes oxygen with the vacuum pump and fills back the melting chamber with inert gas, preventing the oxidation of the alloy in a very fast and efficient way.
Medium frequency induction heating stirs the melted alloy and leads to a perfect homogeneity, while the temperature is constantly monitored by a number of independent temperature controls.
| Model No. | HS-HVCC5 | HS-HVCC10 | HS-HVCC20 | HS-HVCC30 | HS-HVCC50 | HS-HVCC100 |
| Voltage | 380V 50Hz, 3 phase | |||||
| Power | 15KW | 15KW | 30KW | 30KW | 30KW | 50KW |
| Capacity (Au) | 5kg | 10kg | 20kg | 30kg | 50kg | 100kg |
| Maximum temperature | 1600°C | |||||
| Casting rod size range | 4mm-16mm | |||||
| Casting speed | 200mm - 400mm / min. (can be set) | |||||
| Temperature accuracy | ±1℃ | |||||
| Vacuum | 10x10-1Pa; 10x10-2Pa; 5x10-1Pa; 5x10-3Pa; 6.7x10-3Pa （optional） | |||||
| Application metals | Gold, silver, copper, Brass, Bronze, alloys | |||||
| Inert gas | Argon/ Nitrogen | |||||
| Controller system | Taiwan / Siemens PLC touch panel controller | |||||
| Cooling method | Running water / water chiller | |||||
| Wire collecting unit | optional | |||||
| Dimensions | 1600x1280x1780mm | 1620x1280x1980mm | ||||
| Weight | approx. 480kg | approx. 580kg | ||||
Machine pictures
Company Advantages
With first class level quality self-manufactured machines, enjoy high reputation.
Our machines enjoy two years warranty.
Our factory has passed the ISO 9001 international quality certification
We provide a one-stop service for precious metals casting solutions.
Shenzhen Hasung Precious Metals Equipment Technology Co., Ltd. is a mechanical engineering company located in the south of China, in the beautiful and the most fastest economic growing city, Shenzhen. The company is a technological leader in the area of heating and casting equipment for the precious metals and new materials industry.
Our strong knowledge in vacuum casting technology further enables us to serve industrial customers to cast high-alloyed steel, high vacuum required platinum-rhodium alloy, gold and silver, etc.
