Hasung-30kg, 50kg Automatic Pouring Melting Furnace
The equipment adopts tilting type independent handle pouring operation, convenient and safe pouring, the maximum temperature can reach 1600 °C,With Germany lGBT induction heating technology, rapid smelting of gold, silver, copper and other alloy materials, the whole smelting process is safe to operate, when the smelting is completed, only need to pour liquid metal into the graphite mould with handle without press "Stop" button, the machine stops heating automatically.
HS-ATF
Technical Parameters
| Voltage | 380V,50HZ,Three-phase | |
|---|---|---|
| Model | HS-ATF30 | HS-ATF50 |
| Capacity | 30KG | 50KG |
| Power | 30KW | 40KW |
| Melting Time | 4-6Mins | 6-10Mins |
| Max Temperature | 1600℃ | |
| Temperature Accuracy | ±1°C | |
| Cooling Method | Tap Water/Water Chiller | |
| Dimensions | 1150mm*490mm*1020mm/1250mm*650mm*1350mm | |
| Melting Metal | Gold/K-Gold/Silver/Copper And Other Alloys | |
| Weight | 150KG | 110KG |
| Temperature Detectors | PLD Temperature Control/Infraerd Pyrometer(Optional) | |
Applicable Metals:
Gold, K-gold, silver, copper, K-gold and its alloys, etc.
Application Industries:
Gold Silver Refinery, precious metal smelting, medium and small jewelry factories, industrial metal melting, etc.
Product Features:
1. High temperature, with a maximum temperature of up 1600℃;
2. High efficiency, 50kg capacity can complete in 15 minutes per cycle;
3. Easy operation, and user-friendly interface, one-click start melting;
4. Continuous operation, can run continuously for 24 hours, increasing production capacity;
5. Electric til, more convenient and safe when pouring materials;
6. Safety protection, multiple safety protections, use with peace of mind.
Product Display:
Shenzhen Hasung Precious Metals Equipment Technology Co., Ltd. is a mechanical engineering company located in the south of China, in the beautiful and the most fastest economic growing city, Shenzhen. The company is a technological leader in the area of heating and casting equipment for the precious metals and new materials industry.
Our strong knowledge in vacuum casting technology further enables us to serve industrial customers to cast high-alloyed steel, high vacuum required platinum-rhodium alloy, gold and silver, etc.
