Hasung - Full Automatic Gold Bullion Bar Vacuum Casting Machine System Induction Heating Precious Metals
The HS-VF260 gold bar casting machine product covers wide application ranges and can be seen in the field(s) of Metal Casting Machinery. The application of contributes to the smooth and highly efficient manufacturing process of precious metal casting.
Hasung's fully automatic gold bullion vacuum casting machine system uses induction heating technology to efficiently melt and cast precious metals like gold. Its vacuum environment prevents oxidation, ensuring high - purity, high - quality bullion bars. The precious metal casting system's automatic operation, high - precision molds, and real - time monitoring enhance efficiency, reduce errors, and lower waste. Widely used in precious metals processing, it meets diverse customer needs for gold bullion bar production.
Considering the industry development and customers' requirements, Hasung has dedicated to the product development and we've made great achievements. After the Hasung full automatic gold bar making machine was launched, we received good feedback, and our customers believed that this type of product could meet their own needs.
| Place of Origin: | Guangdong, China | Condition: | New |
| Machine Type: | Precious Metals Casting Machinery | Video outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty of core components: | 2 years | Core Components: | PLC, Engine, Motor, Pressure vessel |
| Brand Name: | HASUNG | Voltage: | 380V, 3 phases |
| Power: | 60KW | Dimension(L*W*H): | 2500*1000*800(mm), customized |
| Warranty: | 2 years | Key Selling Points: | Easy to Operate |
| Showroom Location: | None | Applicable Industries: | Manufacturing Plant, Precious Metal Gold Silver Bar Casting Machines |
| Weight (KG): | 2200 | Application: | Gold, karat gold,silver and copper |
| Material: | main components are original from japan and germany | Type: | Induction Furnace |
| Dimensions: | 2500*1000*800(mm) | Technology: | IGBT |
| Duty cycle: | 100% | Max Temperature: | 1600C |
| Specification: | continuous casting gold bullions |
The First-Class Quality and Technology for Precious Metal Casting Equipment Manufacturer in China.
Tunnel Furnace Induction Gold Vacuum Casting Machine System
productivity: 4 blocks/hour, each block weighs 15kg;
Maximum working temperature: 1350-1400 degrees Celsius;
Type of protective gas: nitrogen; Air consumption: 5/H;
Furnace inlet water temperature and generator: up to 21 degrees Celsius;
Total water consumption: 12-13/H;
Required cooling water pressure: 3 to 3,5 bar;
Air flow required for ventilation: 0.1 m/s;
Required air pressure from the furnace: 6 bar;
Report Type and Separator: Graphite 400 oz;
The total area of the furnace installation is 18.2M2, the length is 26500mm, and the width is 2800mm.
The Induction Casting Machine Melting Tunnel Node Is Controlled By The Following Areas/Worksites:
Designed in stainless steel. Application: To pack gold particles into graphite sheets. Main
components: Electric push-step device displacement.
Input parameter area Use:
Restrict outdoor air from entering the tunnel Cooling system: water Main components: mobile partition with pneumatic control, nozzle Inject nitrogen.
Melting zone Usage:
used for smelting gold particles Cooling system: water Main components: inductor lined with refractory cement, infrared
Temperature sensor, nitrogen delivery system
Cooling zone.
partition with pneumatic control, nozzle Inject nitrogen. and vacuum.
Unloading zone.
Designed in stainless steel. Purpose:
Extract the finished product from the report.
Power Module, Overall Module: Power supply: 380v, 50Hz; 3 Phases Generator power:
60kW; others are 20KW. Total power required: 80KW
Control Zone:
Workspace for all furnaces
Why do You Choose Hasung Gold Bar Vaccum Induction Casting Machine?
Hasung precious metal vaccum casting machines compare to other companies
1. It’s a Big different. other companies vacuum are controlled by time.
They are not vacuum.They just pump it symbolically.When they stop pumping, it is not a vacuum. Ours pumps to the set vacuum level and can maintain the vacuum.
2. In other words, what they have are the vacuum setting time. For example, adding inert gas after one minute or 30 seconds is automatic.If it does not reach the vacuum, it will be converted to inert gas. It is In fact, the inert gas and the air are fed at the same time. It is not a vacuum at all. the vacuum cannot be maintained for 5 minutes. Hasung gold casting machine can maintain a vacuum for more than twenty hours.
3.We are not the same. We have drawn a vacuum. If you stop the vacuum pump,it can still maintain the vacuum. For a certain period of time,we will reach the set After setting the value, it can automatically switch to the next step and add inert gas
4.Hasung the original parts are from well-known domestic Japan and German brands.
Products Specifications:
Model No. | HS-VF260-1 | HS-VF260-15 | HS-VF260-30 | ||
Automatic Tunnel Furnace Gold Bar Vacuum Casting Machine | |||||
Power Supply | 380V ,50/60Hz 3 Phases | ||||
Power Input | 50KW | 60KW | 80KW | ||
Max Temp | 1600°C | ||||
Shielding Gas | Argon / Nitrogen | ||||
Temperature Accuracy | ±1°C | ||||
Capacity | 1kg 4pcs 1kg or 5pcs at a mould | 15kg/pcs | 30kg/1pcs | ||
Application | Gold, Silver, Copper | ||||
Vacuum | German Vacuum Pump, Vacuum degree-100KPA (optional) | ||||
Operation method | One-key operation to complete the entire process, POKA YOKE foolproof system | ||||
Control system | Mitsubishi PLC+Human-machine interface intelligent control system (included) | ||||
Cooling type | Water chiller(sold separately) or Running water | ||||
Dimensions | 2500X1200X1060mm | ||||
Weight | 2200KG | ||||
More related products:
FAQ
Q: Are you manufacturer?
A: Yes, we are the original manufacturer of the highest quality products for precious metals smelting and casting equipment, especially for high tech vacuum and high vacuum casting machines. Welcome to visit our factory in Shenzhen, China.
Q: How long does your machine warranty last?
A: Two years warranty.
Q: How is your machine quality? A: Definitely it's the highest quality in China in this industry. All machines apply the best world famous brands name parts. With great workmanship and reliable highest level quality.
Q: Where are your factory located?
A: We are located in Shenzhen, China.
Q: What can we do if we have problems with your machine while using?
A: First, our induction heating machines and casting machines are with highest quality in this industry in China, customers
usually could use it for more than 6 years without any problems if it's under normal condition using and maintenance. If you have any troubles, we'll need you to provide us a video to describe what the problem is so that our engineer will judge and find out the solution for you. Within warranty period, we'll send you the parts free of charge for replacement. After warranty time, we'll provide you the parts at an affordable costs. Long lifetime technical support is offered freely.
Q: Are your products good quality?
Shenzhen Hasung Precious Metals Equipment Technology Co., Ltd. is a mechanical engineering company located in the south of China, in the beautiful and the most fastest economic growing city, Shenzhen. The company is a technological leader in the area of heating and casting equipment for the precious metals and new materials industry.
Our strong knowledge in vacuum casting technology further enables us to serve industrial customers to cast high-alloyed steel, high vacuum required platinum-rhodium alloy, gold and silver, etc.
